Technical Specifications

FINISH: Stainless steel hopper, frame lid, and paddle. Tinned bowl, ring, and auger
MOTORS: Auger: 7 1/2 HP 208V, 60 Hz, 3 Phase
Mixer: 3/4 HP, 208 V 60 Hz, 3 Phase (Other voltages call factory) 50 Hz available
DRIVE SYSTEMS: Auger-single reduction drive chain | Mixer-double reduction chain drive
BOWL TYPE: Size 32, uses size 32 plate and knives
HOPPER CAPACITY: Up to 150 lbs.
OUTPUT CAPACITY: Up to 80 lbs. / minute first grind. Up to 56 lbs. / minute second grind
STANDARD CAPACITY: No inlet (solid tub) hopper, spurt guard, ring wrench, pneumatic footswitch, 11"™ cord and plug, reversible paddles, meat cart less lugs, locking swivel casters with preventz additive, bowl nut wrench, operating and safety manual
OPTIONS: Size 32 plate and knife, electric foot, switch, 35° right and left side hopper inlet with connections for tandem operations, stainless steel bowl and ring (enterprise or unger)
DIMENSIONS (DWH): 52" x 29" x 52"
